QF100TX5CON Manrose Quiet Fan X5 Conceal Timer

Cat. No QF100TX5CON
  • IPX5 rated for compliant zone 1 installation
  • High quality, long life motors continuously rated and warranted for a minimum of 30,000 hours or 3 years
  • Decibel level of ONLY 28dB(A) at 3m.
  • An impressive extraction rate of 75m3/hr, 21 litres per second
  • Low energy motor with a maximum consumption of 6 Watts
Call Us
QF100TX5CON Manrose Quiet Fan X5 Conceal Timer
Product Type Axial Fans
Room Type Bathroom, Ensuite
Warranty 3yr
Adjustable Timer Yes
Grille Type Tile
    The Manrose Quiet Fan X5 Conceal, an ultra quiet bathroom fan for a Zone 1 installation with a stylish flat fascia.
Description The Manrose Quiet Fan X5 Conceal is the latest in domestic ventilation to incorporate a high extraction rate whilst producing an incredibly quiet running volume. Designed for wall and ceiling mounting, this comprehensive range is ideal for bathrooms and toilets.

The unit also comes complete with a performance enhancing turning vane system located in the spigot to improve performance by maintaining a high output.

Speed 1 (l/s) 21
Control Type Run-on Timer
Installation Type Wall, Panel, Ceiling
Running Mode Intermittent
IP Rating IPX5
Shutter Type Spring Return
Max Timer (Minutes) 30
Sound dB(A) @ 3m 28
Power 1 (W) 6
Spigot Diameter (mm) 100
